The MDF-C8V1 VIP ULT chest freezer is a compact –80°C freezer using VIP PLUS insulation to maximize storage and improve energy efficiency. Its single-compressor auto-cascade system delivers higher efficiency in a space-saving design.

Key specs

• Temperature range: ~–60°C to –80°C (down to –80°C)

• Capacity: 84 L (3.0 cu ft)

• Storage: ~42 × 2" cryoboxes

• Refrigeration: single-compressor auto-cascade (mixed refrigerant)


Size & weight

• External (W×D×H): 550 × 685 × 945 mm

• Internal (W×D×H): 405 × 490 × 425 mm

• Net weight: ~67 kg

• Footprint: ~0.37 m²


Features

• Microprocessor control with digital display and alarms (temperature, power failure)

• Energy use: ~7.2 kWh/day | Noise: ~47 dB(A)


Typical uses

• Storage of DNA/RNA samples, cells, and reagents

• Small research and clinical labs

• Backup –80°C storage for critical samples
